Automatic Small Sachet Food Vitamin Powder Pouch Vertical Filling Packing Machine
Automatic Small Sachet Food Vitamin Powder Pouch Vertical Filling Packing Machine
This bottom filling type packing scale is ideal for industries requiring high-precision packaging of ultra-fine, dust-prone powders such as pharmaceutical raw materials, protein powder, carbon powder, cobalt sulfate, fire extinguisher powder, battery materials, and agricultural additives. It is especially suitable for cleanroom environments and operations with strict dust control and material loss requirements. With features like bottom filling, lift degassing, multi-stage auger feeding, and automatic dust recycling, the machine ensures high filling density, improved accuracy, and reduced dust emissions—making it an efficient and cost-effective solution for modern powder packaging needs.
Main features
1.Hopper: The hopper has a 100L capacity and is made of SUS304 stainless steel. It serves as a transitional container for auger feeding. The interior surface is mirror-polished for easy cleaning, while the exterior features a matte finish for durability and appearance.
2.Filling System: Equipped with a single vertical auger, the system uses frequency conversion technology to control motor speed across three levels—fast, medium, and slow. By adjusting preset parameters, the system optimizes the ratio of each speed stage, ensuring high filling speed without compromising accuracy.
3.Weighing System: Utilizes a high-precision load cell with excellent long-term stability and impact resistance. A specialized force transmission structure links the weighing platform and bag clamping mechanism, ensuring consistent and accurate measurements.
4.Lifting and Degassing System: The lifting mechanism moves synchronously with the weighing and bag-holding components to enable bottom filling, which minimizes drop height, reduces dust, and ensures a cleaner working environment. The built-in degassing feature improves material bulk density, enhances bag filling efficiency, and reduces packaging costs.
5.Dust Recycling System: Captures and recycles dust generated during the filling process, returning it to the hopper to minimize material loss and maintain a cleaner operation.
6.Weighing Control Cabinet: Houses key components including a high-quality Canadian Geman weighing indicator, 24V switching power supply, and Schneider relay card. It functions as the central control hub, coordinating the entire packaging process for optimal performance.
Main Technical Data
| Filling weight | 10-30kg |
| Filling Accuracy | ±0.2% |
| Filling Speed | 40-60bags/hour |
| Power Supply | 3P AC208-415V 50/60Hz |
| Total Weight | 510kg |
| Overall Dimensions | 1300x700x2360 |
| Hopper Volume | 100L |
